High frequency plastic welding machine for biogas bag

Model No: ZG-8KWF1
Minimum Order: 1 SET
Delivery Time: 15-45 Working Days
Brand Name: SINOPWR
Place of origin: SHENZHEN

Advantages:

1. Machine is C-shaped and equipped with Vientiane wheel, which is convenient for the movement of the body.
2. Design C-shaped trough and roller device to facilitate stacking and dragging, and save labor.
3. It has the functions of manual/automatic operation.
4. Equipped with a self-made square hf bucket oscillating tube, with high output, stable current and low electric field radiation.
5. Equipped with finely ground guide posts and hollow-out case, which is more convenient for equipment operation.
6. Equipped with highly sensitive spark protection system and overcurrent protection device to protect the equipment and its supporting facilities.

APPLICATIONS:

specailized for welding biogas bag,water container,oil containing bag. and also applied for sealing tarpaulin, sunshading canvas, painting canvas, film curtain and relatives products

Model	ZG-8KW-F1	ZG-10KW-F1	ZG-12KW-F1	ZG-15KW-F1	ZG-25KW-F1
Power	8KW	10KW	12KW	15KW	25KW
Input power	15KVA	18KVA	20KVA	25KVA	35KVA
Voltage	3Phase 220v/380V 50/60HZ or customized
Frequency	27.12MHz
Rectifier	silicon diode
Oscillation tube	7T69RB	E3069	3130RB	8T85RB	8T25RB
Max pressure	400kg	600kg	750kg	1000kg	1200kg
Operation mode	pneumatic
Max distance of electrodes	150mm
The press stroke	150mm
The size of upper electrode	100*700mm	100*800mm	100*900mm	100*1000mm	100*1200mm
The size of lower electrode	450*900mm	450*950mm	450*1050mm	450*1150mm	450*1350mm
deep of throat	750mm
The range of temperature	30~200 ℃ adjustable
Welding time	0---10s Adjustable
Productivity	< 300times/hour
